The Blackline X8 is an ultra-compact, two-way passive loudspeaker that delivers high-output performance from an exceptionally small enclosure. Designed for versatility and ease of use, it combines a powerful 8″ driver with a rotatable high-frequency horn, making it an ideal choice for technical setups requiring a discreet but professional audio solution.
Key Features
- Rotatable HF Horn: The 90° x 50° horn is user-rotatable, allowing for precise pattern control whether the speaker is mounted vertically or horizontally.
- Compact Plywood Enclosure: Built from durable birch/poplar ply with a symmetrical, multi-angle design and finished in a rugged black textured paint.
- Clean Aesthetics: Features a screw-free, cloth-backed perforated steel grille and a removable pole-mount bung to maintain a sleek profile.
- Portable & Riggable: Equipped with an integral ergonomic handle for easy transport and multiple M8/M6 inserts for various mounting and suspension options.
- Professional Connectivity: Includes two NL4 connectors for secure input and simple link-through to additional units.
High-Level Specifications
- Product Type: Ultra-Compact, 2-Way Passive System
- LF Driver: 8″ (200mm) with 2″ (50mm) Voice Coil
- HF Driver: 1″ (25mm) Exit Compression Driver
- Power Handling: 200W AES / 800W Peak
- Nominal Impedance: 8Ω
- Frequency Response (±3dB): 70Hz – 20kHz
- Maximum SPL: 115dB Continuous / 121dB Peak
- Dispersion: 90° H x 50° V (User-Rotatable)
- Dimensions (WxHxD): 257 x 422 x 243mm
- Weight: 8kg (17.6lbs)
